Tonnage = 22 Ton
Stroke = 1.25″
Speed (Variable) = 0-180 SPM
Slide Adjustment = 2″
Shut Height (S.D.A.U.) = 8.75″
Ram Size = 12″ L-R x 8″ F-B
Bed Area = 20″ L-R x 12″ F-B
Motor = 3 HP
Electrics = 220/440V/60HZ/3PH
Weight (Approx.) = 4,900 lbs.
Minster Air Clutch and Brake
Cieco K-2000 Press Control with Time-Based Brake Monitor
Dual Safety Clutch Valve
Recirculating Lubrication System
Floor Operator Control
1.5″ Bolster (Center Cutout 11″ L-R x 7″ F-B)
(4) Isolation Mounts
