Used MINSTER 90-1200 | Presses, Knuckle Joint

Press Specifications:

·         1200 U.S. Tons Cap. at bottom of stroke (10,676 kN)
·         6.00 in. Stroke (152 mm)
·         0.50 in. Slide Adjustment (13 mm)
·         38.00 in.  width between Uprights (965mm)
·         31.50 in. width between Gibs (800 mm)
·         30.25 in. Shutheight, SDAU, on Bed (768 mm)
·         21.00 x 13.25 in. Slide Area (533 mm x 337 mm)
·         40.00 x 38.00 in. Bed Area (1016 mm x 965 mm)
·         1.12 in. diameter Bed Opening (28 mm)
·         16 SPM
·         30 HP Drive Motor (22 kW)
·         480VAC/60Hz/3ph Incoming Voltage
