MECON Servo Roll Feed - Straightener Combination 24" Wide
Stock thickness capacity: .156" x 24" Wide
Stock thickness capacity: .210" x 12" Wide
Equipped With:
Four inch diameter feed rolls
Matt chrome finish on upper and lower rolls
Piloting upper roll lift (air operated)
Five roll straightener
Individual upper roll adjustment
Adjustable stock width edge guides
Stand mounted
Adjustable pass line
NEW AC servo roll feed drive and control package with STO (safe torque off) function
Touchscreen HMI operator interface
Job memory micro adjust batch count etc (Consult sales for complete details)
Free standing sloped front servo roll feed control console
Remote pendant control for jog forward and reverse
Fused disconnect
480 Volt
Auto Mode
Control does not possess advanced safety (SLS -safe limited speed or SOS-safe operating stop) as their use would be a purchaser responsibility. These functions are additional costs and require longer lead times - consult sales.
Reconditioned, painted and 100% cycling. New servo drive and controls
Warranty: MDNA Standard 30 Day return privilege on entire machine / One year parts labor on new controls
Terms: 40% Deposit, net prepaid
