500 ton Straight Side 1600x1400 mm / 63" x 55"

500 ton Straight Side 1600x1400 mm / 63" x 55"

Have one to sell?
1 226 344 9956
carlos@PressTrader.com
ConditionNew
1 available
Have one to sell?

Overview

Type:
Straight Side Presses
Manufacturer:
AOMATE
Model:
APN-500
Condition:
New - In-Stock
Year:
2022
Status:
For Sale

Description

Tonnage - 500 ton
Rated point - 7
Frame - H TYPE, ONE BLOCK
Mode: continous, manual, inch
Cltuch Type: DRY
Drive system: CRANK
Stroke: 250 mm
S.P.M 25-50
Shut height: 600 mm
Slide adjustment: 120 mm
Bolster area: 1600*1400*220 mm
Slide area: 1600*1400 mm
Side opening: 1200*700 mm
Lubrication: Grease
Max upper die weight: 1500 kg
Power 380v /50 HZ
Filter cover for automobile with max 3mm thick, Progressive die
UL Cerificate - N/A
Delivery: 30 DAY

Type of PressMechanicalMechanical
Tonnage500 T453.593 t
Bolster (LR)62.992"1,600 mm
Bolster (FB)55.118"1,400 mm
Stroke9.8425"250 mm
Shut Height23.622"600 mm
Min SPM25 strokes/min.25 strokes/min.
Max SPM50 strokes/min.50 spm
Vari Speed (Yes/No)YesYes
Ram (FB)62.992"1,600 mm
Ram (LR)55.118"1,400 mm
Air Clutch (Yes/No)YesYes
Slide Adjustment4.7244"120 mm

Tonnage - 500 ton
Rated point - 7
Frame - H TYPE, ONE BLOCK
Mode: continous, manual, inch
Cltuch Type: DRY
Drive system: CRANK
Stroke: 250 mm
S.P.M 25-50
Shut height: 600 mm
Slide adjustment: 120 mm
Bolster area: 1600*1400*220 mm
Slide area: 1600*1400 mm
Side opening: 1200*700 mm
Lubrication: Grease
Max upper die weight: 1500 kg
Power 380v /50 HZ
Filter cover for automobile with max 3mm thick, Progressive die
UL Cerificate - N/A
Delivery: 30 DAY
